Aperçu technique
Kit cadre
Cadre:
Lightweight aluminium with Powder Coat Finish | 1 1 / 8" head tube | 140mm post mount | 9 x 135mm QR
Fourche:
Lightweight Aluminium with Powder Coat Finish | 140mm Post Mount | 9 X 100mm QR
Cockpit
Potence:
BMC | 35mm Length | 6° Angle
Cintre:
SDG Slater | 650mm Wide | 20mm Rise | 5° Sweep | 31.8mm Clamp
Seat
Tige de Selle:
Alloy | 27.2mm Diameter | 300mm Length | 15mm Offset
Selle:
SDG Fly Jr
Transmission
Pédalier:
Lightweight Forged Alloy Cranks | 140mm Length
Plateaux:
32T
Cassette:
Sunrace
Taille de cassette:
11-34T
Chaîne:
SRAM
Dérailleur Arrière:
SRAM X4 | Medium Cage
Leviers de Vitesses:
SRAM X4 Trigger
Vitesses:
1 x 8
Boîtier de pédalier:
BSA Threaded Bottom Bracket
Freins
Leviers de Frein / Étriers:
TEKTRO HD-M286 | Short Reach Levers
Disques:
TEKTRO TR140-22
Largeur de Pedalier:
S-M: 160/160 S-M | L-XL: 180/160
Roues
Jantes:
DD32
Moyeux:
CNC Machined Alloy | Sealed Bearings | Quick Release
Pneus:
Kenda Booster | 24 x 2.4"
Informations supplémentaires
Espace pour les pneus:
58mm measured tire
Classification ASTM:
Level 3
Limite de poids du système:
60kg
Règlement relatif à la sécurité générale des produits (GPSR):
Consignes de sécurité GPSR (UE)
Personne responsable conformément au GPSR (UE)
| Size | 24" |
|---|---|
| Rider Height | 120-145 |
| Reach | 350 |
| Stack | 507 |
| Bar Rise | 20 |
| Bar Sweep | 5 |
| Bar Width | 650 |
| BB Drop | 40 |
| Crank Length | 140 |
| Fork Length | 412 |
| Fork Rake | 40 |
| Front Center | 538 |
| Head Tube | 105 |
| Head Tube Angle | 68 |
| Rear Center | 392 |
| Seat Angle | 73 |
| Seat Tube | 300 |
| Seatpost Length | 300 |
| Seatpost Offset | 15 |
| Standover Height | 580 |
| Stem Angle | ±6 |
| Stem Length | 35 |
| Top Tube | 505 |
| Trail | 82 |
| Wheelbase | 972 |
